Model No. | NIE BDST 1.0T/3.0M | NIE BDST 1.0T/3.5M | NIE BDST 1.5T/4.5M |
---|---|---|---|
Capacity (KGs) | 1000 | 1000 | 1500 |
Lifting Height (Mm) | 3000 | 3500 | 4500 |
Load Centre (Mm) | 400 | 400 | 600 |
Max. Mast Height (Mm) | 3555 | 3975 | 4985 |
Fork Length (Mm) | 1150 | 1150 | 1150 |
Fork Width (Mm) | 570 | 570 | 580 |
Minimum Fork Ht. (Mm) | 90 | 90 | 90 |
Turning Radius (Mm) | 1620 | 1620 | 1520 |
Overall Length (Mm) | 1955 | 1955 | 1960 |
Overall Width (Mm) | 855 | 855 | 850 |
Minimum Mast Ht. (Mm) | 2075 | 2275 | 2055 |
